Series 34
Maintenance free LED navigation lights
Description
LED navigation lights. The latest LED generation in an attractive and slim design. Totally maintenance-free. The series 34 is specially designed for sailing boats < 50 m / 164 ft. (Bicolor: < 20 m / < 65 ft.)
The navigation lights fulfil all requirements of the "International Regulations for Preventing Collision at Sea 1972 (COLREG)", published by the international Maritime Organization (IMO) and local rules.
The application is depending on the visibility requirements.
This series is available for all markets worldwide.
Technical specifications
Electrical specification
- 12 - 24 V DC, +/-20%. Mulivolt, invers polarity protection included, EMC tested,with degradation control,LED(s) included, 2 x 1.5 mm², self-protective insulation, class II.
Mounting
- Side-mount, pre-wired with 140 mm cable 2 x 0.30 mm2/ AWG 22, 2-hole mounting. All masthead(masthaed/anchor) and tricolor (tricolor/anchor) lights are equipped with quicfits system and are deck-mounted.
Optic
- Innovative lens technology for wide visibility with one or twolight-emitting diodes (depending on article).
Housing
- Polycarbonate, seawater resistant, UV protected, non-corrosive, non-magnetic, impact and shock resistant.
