Description

The RLX B G2 is the improved second generation of the very popular RLX B. It is designed as a small and robust 24VDC floodlight for marine applications, with fixed and molded cables in standard lengths of 5m and 15m. The RLX B G2 is a reliable product that will perform dependably, even in the harshest marine environments for many years to come. Typical applications for the RLX B G2 are fast ferries, smaller fishing vessels, SAR vessels, pilot vessels, CTVs and offshore wind installations. As a standard the RLX B G2 is delivered with CRI80, 5000K and 3 different beam options MB30, MB50 and Wide. It’s also available with 3000K, red, green and blue light colors. For VAC installations the RLX B G2 can be delivered as a bundle, with an external Junction box including LED driver, or can be mounted with a separate LED driver.

Technical specifications

  • Initial lumious flux

    1. 4.800 - 5.200lm
  • Light colour temperature

    1. 5.000K or 3.000K
  • Color Rendering Index

    1. 80
  • Beam angle

    1. MB30°, MB50° or WB90° beams
  • Input voltage

    1. 19 - 32 VDC
  • Input power

    1. 40W
  • Ambient temperature (Ta)

    1. -40°C to +55°C
  • Ingress protection

    1. IPx6/IPx7
