O85-S
Decorative outdoor LED luminaire.
Description
O85-S is a decorative wall or ceiling LED luminaire for residential or commercial use. Available in three different sizes and four colours; black, white, aluminium grey or anthracite.
O85-S is manufactured with housing made of die-cast and turned aluminium. Polyester powder coated paint finish. Opal satin polycarbonate diffuser. Supplied with silicon gasket and screws in stainless steel.
Technical specifications
Driver
- Fixed output (HF).
Connection
- 2 x membrane glands (cable ø 5-9 mm).
3 pole 2.5 mm² push-in terminal block prepared for through wiring.
Outdoor use requires suitable flexible cables assuring the water tightness of the membrane gland.
- 2 x membrane glands (cable ø 5-9 mm).
Mounting
- Installation directly on the ceiling or wall.
Light Source
- LED 800 - 2700 lumen out
Colour temperature 3000/4000 K, CRI Ra 80, MacAdams 3
- LED 800 - 2700 lumen out
Body material and colour
- Housing in die-cast and turned aluminium. Polyester powder coated paint finish. Available in colour; black (close to RAL 9005), white (close to RAL 9016), aluminium grey (close to RAL 9006) or anthracite (close to RAL 7043). Opal polycarbonate diffuser. Supplied with silicon gasket and screws in stainless steel. The screws are covered by a frame fixed by magnets.
