MINI GAMMA
Description
MINI GAMMA is a LED luminaire for recessed installation on walls. Well suited for use in staircases where it provides increased safety on stairs. Available in different designs.
MINI GAMMA is manufactured with luminaire housing in diecast aluminium. Polyester powder coated paint finish. Black or white. Frame in brushed stainless steel as option. The diffuser is supplied in opal tempered glass. The luminaire has silicone gasket and all screws are made of stainless steel.
The mounting box is included and is made of technopolymer.
Technical specifications
Driver
- Fixed output (HF)
Body material and colour
- Luminaire housing in diecast aluminium. Polyester powder coated paint finish. Black (RAL 9005) White (close to RAL 9001) Frame in brushed stainless steel as option. Diffuser in opal tempered glass. Silicone gasket. Screws made of stainless steel.
Connection
- Cable inlet through membrane glands on backside of the luminaire..
3pole2.5 mm² screw terminal block..
.
Outdoor use requires suitable flexible cables assuring the water tightness of the membrane gland.
- Cable inlet through membrane glands on backside of the luminaire..
Light Source
- LED 100 - 500 lumen out.
Colour temperature 4000 K, CRI Ra 80, MacAdams 3.
On request: 3000 K
- LED 100 - 500 lumen out.
Mounting
- Installation into supplied mounting box.
